RYAN has a few hundred kinds of power units for different applications, which are compactly intergrated with high-pressure gear pumps, DC motors, integrated valve manifolds, fuel tanks and other components.
1. High-pressure gear oil pump / DC motor / Manual switch
2. Pressure limiting relief valve
3. The descent speed is adjustable
| Model | DC-F06-2.6/E-2.2/24/**-8HS-A |
| Voltage | DC 24V |
| Power | 2.2kW |
| Speed | 2500rpm |
| Disp. | 2.6 cc/r |
| Pressure | 16 MPa |
| Volume | 8L |
| Size | P, T: M14x1.5 |
RYAN semi-electric stacker power packs 1 are widely used in aerial work platform and automobile tail gate.
