As a strategic supplier of many well-known AWP manufacturers, RYAN can not only provide the main power source for the system, but also provide functions such as lifting function, walking function, steering function, emergent start, no-load start, etc.
1. High pressure gear oil pump / DC motor / Multipurpose integrated valve block/ Hydraulic valve / Tank
2. 3-position 4-way solenoid valve / 2-position 4-way solenoid valve
3. External oil return filter
| Model | DC-F64-1.5/F-2.0-24/20-4PH-FK |
| Voltage | DC 24V |
| Power | 2.0kW |
| Speed | 3100rpm |
| Disp. | 1.5 cc/r |
| Pressure | 24.5 MPa |
| Volume | 4L |
| Size | SAE4, SAE6 |
RYAN aerial working platform power packs 13 are widely used in aerial work platform and automobile tail gate.
